//ICC-AVR application builder : 2007-7-18 13:01:11
// Target : M16
// Crystal: 7.3728Mhz
// 作者：古欣
// AVR與虛擬儀器 [url]http://www.avrvi.com[/url]
// 功能：SPI主機模式，循環發送從1~255

#include <iom16v.h>
#include <macros.h>

void port_init(void)
{
PORTA = 0x00;
DDRA = 0x00;
PORTB = 0x00;
DDRB = 0x00;
PORTC = 0x00; //m103 output only
DDRC = 0x00;
PORTD = 0x00;
DDRD = 0x00;
}

//SPI initialize
// clock rate: 57599hz
void spi_init(void)
{
PORTB |= (1<<PB4) | (1<<PB5) | (1<<PB6) | (1<<PB7);
DDRB |= (1<<DDB5) | (1<<DDB7) | (1<<DDB4);     //Set MOSI, SCK AND SS as outputs
SPCR = 0x73; //setup SPI
SPSR = 0x00; //setup SPI
}

//call this routine to initialize all peripherals
void init_devices(void)
{
//stop errant interrupts until set up
CLI(); //disable all interrupts
port_init();
spi_init();

MCUCR = 0x00;
GICR = 0x00;
TIMSK = 0x00; //timer interrupt sources
SEI(); //re-enable interrupts
//all peripherals are now initialized
}

void SPI_MasterTransmit(char cData)
{
PORTB &=~ (1<<PB4); //強制接收方進入從模式
SPCR |= (1<<MSTR); // MSTR有時會被清零，這里強制進入主機模式
/* 啟動數據傳輸 */
SPDR = cData;
/* 等待傳輸結束 */
while(!(SPSR & (1<<SPIF)))
;
PORTB |= (1<<PB4);
}

void Delay(void) //延時，沒有詳細計算
{
unsigned int i,j;
for(i=1000;i>0;i--)
{
for(j=200;j>0;j--)
;
}
}

void main(void)
{
unsigned char i=0;
init_devices();
while(1)
{
for(i=255;i>0;i--)
{
SPI_MasterTransmit(i);
Delay();
}
}
}

//ICC-AVR application builder : 2007-7-18 12:56:10
// Target : M16
// Crystal: 7.3728Mhz
// 作者：古欣
// AVR與虛擬儀器 [url]http://www.avrvi.com[/url]
// 功能：從機模式，中斷方式接收，并在LED上顯示

#include <iom16v.h>
#include <macros.h>

void port_init(void)
{
PORTA = 0x00;
DDRA = 0xFF;
PORTB = 0x00;
DDRB = 0x00;
PORTC = 0x00; //m103 output only
DDRC = 0x00;
PORTD = 0x00;
DDRD = 0x00;
}

//SPI initialize
// clock rate: 57599hz
void spi_init(void)
{
SPCR = 0xE3; //setup SPI
SPSR = 0x00; //setup SPI
}

#pragma interrupt_handler spi_stc_isr:11
void spi_stc_isr(void)
{
//byte in SPDR has been sent/received
PORTA = SPDR;
}

//call this routine to initialize all peripherals
void init_devices(void)
{
//stop errant interrupts until set up
CLI(); //disable all interrupts
port_init();
spi_init();

MCUCR = 0x00;
GICR = 0x00;
TIMSK = 0x00; //timer interrupt sources
SEI(); //re-enable interrupts
//all peripherals are now initialized
}

void main(void)
{
init_devices();
DDRB|=(1<<PB6); //MOSI 設置為輸出
while(1)
;//等待中斷
}
